Power Requirements for Horizontal Flight in the Pigeon Columba Livia

The primary aim of this paper is to estimate the mechanical power required for a pigeon to fly at various speeds. Although this is only one aspect of ‘performance’ in powered flight, it is perhaps the most informative, and sheds much light on more general performance limitations in flying animals.

Most small and medium-sized flying animals are able to hover, at least for short periods, and they thus share with helicopters the ability to fly horizontally at any speed from zero up to some maximum. Like helicopters, they use the whole lifting surface for propulsion as well as for balancing the weight, instead of using a physically separate source of thrust as in a fixed-wing aeroplane. The more general principles of helicopter theory also apply to flying animals, and are adapted here to investigate the power requirements of the pigeon. Among several excellent textbooks on helicopter engineering, that of Shapiro (1955) has been found especially useful.

The conclusions of the present study are in general agreement with those of Tucker (1968), who made respirometric and other measurements on budgerigars (Melopsittacus undulatus) flying in a wind-tunnel. The present power calculation is based entirely on mechanical observations, and provides indirect estimates of such quantities as oxygen consumption, range and endurance, and may thus be regarded as a complementary approach to the same general problem.

The same pigeons (Columba livia) were used as those on which the previous paper (Pennycuick, 1968) was based. Some of the data required in the calculation were derived from the gliding measurements described in that paper, others from further experiments described below, in which the same wind-tunnel and training technique were used. In all the experiments described in this paper the wind-tunnel was set with its axis horizontal, and observations were made with a Bell and Howell 70 DA 16 mm. ciné camera running at 42·6 frames/sec. (determined by filming a clock at the end of each film). Three camera positions were used (Fig. 1): (1) 1·9 m. downstream of the bird, level with the bird and looking upstream; (2) 6·0 m. above the bird, and 1·9 m. downstream; (3) 1·0 m. to one side, looking at right angles to the airstream.

Additional information was obtained from a film of free-flying pigeons taken on the laboratory roof with a Milliken high-speed camera running at 400 frames/sec. This film was taken by John Hadland (Photographic Instrumentation) Ltd. for the to whom I am most grateful for giving me a copy, and allowing me to use it for research purposes.

Various quantities required in the power calculation were measured as functions of forward speed, as follows:

Sweep angle is defined as the aggregate angle swept through by the humeri of both wings during the downstroke. It was determined by filming a pigeon in horizontal flight from behind (camera position 1, Fig. 1). The film was later back-projected onto squared paper and examined frame by frame. Figure 2 shows tracings of two frames, at the beginning and end of a downstroke. The angle between the estimated positions of the humeri was measured at each position, and the difference between these angles gives the sweep angle for that stroke. Pigeons did not fly absolutely steadily in the tunnel, and in practice both sweep angle and wingbeat frequency varied periodically, with a tendency for bursts of vigorous flapping every 5–10 wingbeats. The graph of Fig. 3 is based on an average of 30 wingbeats for each point.

Wingbeat frequency was determined simultaneously with sweep angle, by counting frames over a whole number of wingbeats, starting and finishing at the beginning of a downstroke. The results are plotted in Fig. 4.

The points for zero speed in Figs. 3 and 4 are derived from the high-speed film referred to on page 528, which was taken in anticyclonic conditions, with no detectable wind. Two sequences were found, one of 5 and one of 8 wingbeats, in which a pigeon remained approximately stationary, and the wingbeat frequency was 6·9/sec. in both cases. The sweep angle was assumed to be the maximum recorded by Pennycuick & Parker (1966), 284°. The zero-speed points of Figs. 3 and 4 are somewhat more conjectural than the others, because of uncertainty that the birds’ airspeed really was zero.

When a bird hovers it beats its wings back and forth horizontally, and the faster it goes, the more nearly the plane in which the wings beat becomes vertical. The ‘inclination of the flapping plane’ is defined as zero when the wings beat horizontally, and 90° when they beat vertically. It was measured from a film taken from camera position 3 (Fig. 1), in which the pigeon was photographed against a background consisting of a white card, ruled with black lines parallel to the airflow. The film was back-projected frame by frame onto squared paper, one axis of which was aligned with these lines. The position of the leading edge of the wing at the wrist joint was marked at the beginning and end of the downstroke as shown in Fig. 5, and the acute angle between the airflow and the line joining the two marks was measured. Measurements were made on an average of 20 wingbeats at each speed, in order to minimize errors caused by movement of the pigeon upstream or downstream. The results are plotted in Fig. 6.

In horizontal flight at constant speed power is absorbed in three ways: (1) Induced power—the power needed to impart downward momentum to the air, sufficiently rapidly to produce a reaction balancing the bird’s weight; (2) profile power—the power needed to overcome the profile drag of the wing; (3) parasite power—the power needed to overcome the drag of non-lifting parts, i.e. the body in the case of a bird.

In non-horizontal flight one must also include climbing power, which is equal to the product of the weight, and any upward component of speed. A particular climbing case is considered on page 544.

The power required for a pigeon to fly horizontally at speeds ranging from o to 22 m./sec. was estimated with the aid of Bristol University’s Elliott 503 computer. The above three components of power were calculated in turn, as follows.

In horizontal flight, the upward reaction on the wings must equal the weight, and this implies that the rate at which downward momentum is imparted to the air is numerically equal to the weight. This rate of change of momentum is the product of a downward induced velocity and the mass of air to which this velocity is imparted in unit time.

Considering the hovering case first, the bird’s body remains stationary and the wings beat horizontally, sweeping out an area (as seen from above) which is referred to as the disk area (S_d) (Fig. 7). The airflow through the wing disk is entirely due to the induced velocity V_iz. The following simplifying assumptions, which give good approximations in calculating helicopter performance, are adopted here. (1) The induced velocity is assumed to be constant over the entire disk area. (2) An abrupt pressure rise is assumed to occur as the air passes downward through the disk. This pressure increment, multiplied by the disk area, must, of course, equal the bird’s weight. Half of the pressure step is assumed to be contributed by an area of reduced pressure (relative to ambient) above the wing disk, and half by increased pressure below it.

The term ‘induced velocity’ (V_iz) here refers to the velocity with which the air passes through the wing disk, and it reaches this velocity as a result of accelerating downwards into the area of reduced pressure above the wing disk. Because there is a similar pressure gradient below the bird, the air continues to accelerate downwards after passing through the wing disk, and eventually reaches a velocity of 2V_iz far below the bird. This is proved in all textbooks on helicopters, and is illustrated diagrammatically in Fig. 8.

In view of the finding in the previous paper (Pennycuick, 1968) that wing-span in gliding flight is progressively reduced with increasing speed, it might be wondered whether the same is true in horizontal flapping flight, and a film was taken from above (camera position 2 in Fig. 1) in order to check this point. It was found that the wings were extended to their full span on the downstroke at all speeds at which the pigeon would fly horizontally. On the upstroke, however, span was reduced at high speeds in roughly the same way as in gliding. In fast flight the pigeon extends its wings fully at the start of the downstroke, and at the bottom of the downstroke it flexes the carpal joints, and keeps them flexed during the upstroke. The alternate flexion and extension of the carpal joints is clearly seen in the high-speed film of free-flying pigeons.

The fact that the wings only sweep through some 170° out of the full 360° of the disk at medium speeds is of no account. For the purpose of calculating mass flow, ‘disk area’ remains the full circle, whose diameter is equal to the wing-span, whether the wings are flapped or not. The induced velocity for a fixed-wing aeroplane or glider is calculated by considering the mass flow through a circle, whose diameter is equal to the wing-span.

In forward flight the drag of the body has to be overcome by imparting backward momentum to the air, and this horizontal component of induced velocity can be calculated in basically the same way as the vertical component. The horizontal induced velocity increases progressively with speed, and amounts to about 0·1 % of the forward speed. The power needed to generate it would not reach 0·02 W. over the speed range considered, and can be neglected. For similar reasons as apply in the case of vertical induced power, the induced power needed to overcome a given drag is inversely proportional to the square root of the disk area. Thus much less induced power is needed to overcome body drag if the whole wing is flapped than if the thrust is derived from a propeller or jet, whose diameter is much smaller than the wing span.

The calculation of profile power is somewhat laborious, and could not have been undertaken without using the computer. The difficulty is that the speed and direction of the relative airflow is different at every point along a flapping wing, so that the behaviour of the whole wing has to be approximated by some form of strip analysis. The following calculation refers only to the downstroke, profile power on the upstroke being estimated separately on page 538.

The outline of one wing of the pigeon on whom most of the wind-tunnel measurements were made was traced on graph paper, and the tracing was divided span-wise into thirty-two strips, each 1 cm. wide. The areas of these strips were measured, S_i being the area of strip i (see appendix). Each strip was assigned a flapping radius, that is, the distance of its assumed centre of lift from the centre of rotation of the head of the humerus. The arrangement of strips was such that the flapping radius r_i of strip i was i cm.

V_iz was first calculated (see p. 534), and hence the magnitude of the resultant velocity V_r (Fig. 9) where

Figure 10 shows V_r and V_fi, and their resultant V_ri, which is the local resultant velocity at strip i. V_ri is inclined at an angle B_i to the horizontal. It can be seen from Fig. 10 that

Having found a value for C_DO which is assumed to apply to the whole wing, the profile drag of each strip can now be calculated, and hence the power needed to overcome the profile drag of the whole wing. This profile power may conveniently be divided into two components: P_pro1 is the power needed to maintain the wing’s angular velocity in the downstroke, while P_pro2 is that needed to overcome that component of the profile drag which opposes the forward movement of the whole bird.

(a) P_pro1

In fast flight the wing could well be elevated passively; it is difficult to estimate the work done (if any) by the flight muscles during such elevation, but this would certainly be small, and is neglected. Some power must, however, be needed to counteract the retarding effect of wing profile drag on the forward motion of the bird, and to allow for this P_pro2 is doubled. This may be pessimistic, since wing-span and area are reduced during the upstroke in fast horizontal flight, which should produce a reduction of wing profile drag (Pennycuick, 1968). Any such saving is difficult to estimate, however, and at present doubling P_pro2 is the best method available for allowing for wing profile drag during the upstroke. It is assumed, in effect, that P_pro2 is present during the downstroke only, whereas P_pro2 continues throughout both the downstroke and the upstroke.

At very low speeds elevation of the wing is certainly active (Brown, 1948), and some work is done, presumably by the supracoracoideus. Pennycuick & Parker (1966) estimated that the maximum work done in one contraction by the supracoracoideus would be 8·5 % of that done by the pectoralis, and on this basis one could suggest that the supracoracoideus should contribute about 0·26 W. to the profile power during hovering, when this component is presumably maximal. This is conjectural, however, and, as this component appears to be small, it too is neglected.

Strictly speaking, the profile power calculation refers only to the mid-point of the downstroke, except in hovering, where the wingbeat plane is horizontal. At low speeds, where the wingbeat plane is nearly horizontal, the error from this source would be small, whereas at higher speeds the sweep angle is reduced and the wing can be assumed to do most of its work within ± 30° of the horizontal position. This complication has therefore been neglected.

The relation between C_DO and C_L (Fig. 11) is based on the gliding measurements of the preceding paper (Pennycuick, 1968), where the observations at high C_L refer to the fully extended wing, while those at low C_L refer to the wing with carpal joint flexed. It was not possible to test the extended wing at low lift coefficients. In horizontal flight the wing is extended during the downstroke at all speeds, and it is possible that at high speeds the estimated profile-drag coefficient is in error because of this.

At very low speeds the lift coefficient far exceeds the maximum obtainable in gliding pigeons, so that one has to guess at the profile-drag coefficient. The curve has been extrapolated on the assumption that at a lift coefficient of 2·8 a profile drag coefficient of 0·54 would prevail, which it is hoped is a sufficiently pessimistic assumption. The left-hand end of the curve has also been adjusted; it was explained in the preceding paper (Pennycuick, 1968) that the very low values of wing profile drag obtained at high gliding speeds are subject to some doubt, so in order to avoid the risk of undue optimism the curve was made to give a minimum C_DO of 0·01, ignoring the lowest experimental points which are in the region of 0·003.

It can be seen that because of these various reservations the estimated profile power is subject to rather more doubt than the other two components.

From the results of the preceding paper C_Dp was taken to be 0·43 and S_p was taken to be 36 cm.²—that is, the body was taken to be equivalent to a flat plate 15·5 cm.² in area. It may be noted in passing that this constitutes a parasite-drag ratio of 0·0044 ; that is, the ratio of the equivalent flat plate area of the body to the disk area. This would be considered a medium value of parasite-drag ratio in helicopter practice (Shapiro, 1955).

The three calculated components of power are plotted against speed in Fig. 12. Induced power is 8·4 W. in hovering, but declines rapidly as speed is increased, and falls below 2 W. at speeds above 9 m./sec. Parasite power, on the other hand, is negligible at low speeds, and remains below 1 W. up to 10 m./sec., after which it increases rapidly to become the largest component above 19 m./sec. Profile power is roughly constant between 5 and 6 W. over the range 3–18 m./sec., and is the largest component over most of the speed range, from about 4 to 19 m./sec.

Although the power calculation contains many assumptions and approximations, the more important of which have (it is hoped) been pointed out, there is no reason to doubt that the main trends are as shown in Fig. 12–that is, the induced power is high in hovering and drops sharply with increasing speed, the parasite power starts at zero, and increases with roughly the cube of the speed, and the profile power is substantial at all speeds.

The sum of the three components is the total power required to fly at any particular speed, and this is also plotted against speed in Fig. 12. The calculated total power is about 11·5 W. in hovering but declines steeply as speed is increased to a minimum of 8·7 W. at 8–9 m./sec. Above this speed the total power again rises. The slight hump in the curve of Fig. 12 at about 1 m./sec. results from the very high drag coefficient assumed to prevail at low speeds, and should not be taken too literally.

The minimum-power speed, about 8–9 m./sec., is about the same as the minimum gliding speed (about 8·6 m./sec.), and the power required to fly at this speed is only about three-quarters of that required in hovering. It is the speed at which the bird should fly if its object is to remain airborne for as long as possible on a given amount of fuel—but not if it needs to travel the maximum possible distance for a given amount of fuel.

To assess a pigeon’s effective range, a large (471 g.) male pigeon was killed, and the total fat was extracted with hot chloroform in a Soxhlet apparatus; 37·4 g. of fat were extracted. If the pigeon were to oxidize the whole of this by flying at its maximumrange speed of 16 m./sec., it would travel about 400 air km., and be airborne for about 7 hr. The pigeon used for this estimate had been kept on a ration of 28 g. of mixed seed per day, which would be normal for racing pigeons flying on mediumdistance races of 300 km. or so. A fat pigeon would probably contain at least twice as much fat as the one extracted. Exceptionally good racing pigeons do on occasion home over distances as great as 800 km. in a single summer’s day, with perhaps 15 hr. flying time. On the basis of the above calculation, this would call for a usable fat store of some 70 g., which would appear quite feasible.

In a fixed-wing aircraft flying horizontally at a constant speed V the weight W is balanced by the lift L provided by the wings, and the drag D is balanced by the thrust T of the propeller or jet (Fig. 14). The power required, P, is then

The curve of (L/D)_eff versus speed for the pigeon has the same form as the range curve of Fig. 13, and is shown on the same graph. Its maximum value is estimated to be 5·9. This is a poor value by helicopter standards, where values of (L/D)_eff of 15 are commonly obtained, and 20 is not unknown. The poor estimated performance for the pigeon is partly due to the high wing profile coefficients assumed, and partly to the large equivalent flat plate area of the body. Both quantities are derived from gliding measurements, and there are no grounds at present for regarding them as pessimistic.

An estimate of effective lift: drag ratio for a smaller bird, the blackpoll warbler Dendroica striata, can be obtained from figures given by Nisbet, Drury & Baird (1963) for fat consumption during long migratory flights over the sea. By comparing the fat stores of samples of birds taken before and after a sea crossing, they estimated that these birds, whose average weight was 19·0 g. wt., used 1·02 kcal, of chemical energy per hour. If one-fifth of this is assumed to have been converted into mechanical work, the average power output would be 854 J./hr. The birds are stated to fly at about 20 knots (37 km./hr.). Substituting these figures in equation (26) yields an effective lift: drag ratio of 8·1. When it is remembered that the figure given by Nisbet et al. (1963) for fat consumption represents a minimal estimate, so that the resulting estimate of (L/D)_eff is likely to err on the high side, the agreement with the value estimated above for the pigeon is remarkably close.

The recent respirometric measurements of Tucker (1968) on the budgerigar (Melopsittacus undulatus) provide another estimate of (L/D)_eff in a different species, by another method again. At the minimum-power speed (35 km./hr.) the oxygen consumption of a budgerigar weighing 35 g. wt. was found to be 10·2 ml./min. in excess of resting metabolism. Assuming that 4 J. of mechanical work are done per ml. of oxygen consumed, the power output would be 0·68 W., and the effective lift: drag ratio 4·9 (from equation 26). Similarly, measurements of oxygen consumption at 28, 42 and 48 km./hr. yield estimates for (L/D)_eff of 3·8, 4·9 and 4·0 respectively.

If one assumes that 2·03 1. of oxygen are required to oxidize 1 g. of fat (Prosser & Brown, 1961), then the oxygen consumption corresponding to the mechanical power output at the minimum power speed would be 132 ml./min. To this must be added 5 ml./min. for resting metabolism (Lasiewski & Dawson, 1967), making 137 ml./min. in all, as an estimate of the minimum possible oxygen consumption for a pigeon in continuous horizontal flight. At the maximum-range speed the figure would be 168 ml./min. There is little doubt that pigeons can fly continuously at this speed, as Michener & Walcott (1967) record cruising speeds ranging from 13 to 18 m./sec. in different homing pigeons, so the above argument, if correct, implies that pigeons are capable of absorbing oxygen continuously at a rate of 170 ml./min. or so.

There is equally little doubt that pigeons are not able to remain in oxygen balance while hovering. They can hover for a few seconds, but presumably rely on the white fibres of the pectoralis to do this (George & Berger, 1966), and incur an oxygen debt.

It follows that the maximum power which a pigeon can produce without incurring an oxygen debt must lie somewhere between that required to cruise at the maximum-range speed and that required to hover, and this defines a speed range (with a lower as well as an upper limit) over which continuous flight is possible. For instance, if 16 m./ sec. is assumed to be the upper limit, one can draw a horizontal line at about 10·5 W. in Fig. 12 representing the maximum continuous power output. The pigeon would then be able to fly in oxygen balance at speeds between 3 and 16 m./sec., but would incur an oxygen debt at both lower and higher speeds.

To complete the diagram, one also needs to know the maximum power which the pigeon can achieve in short bursts of activity, for instance at take-off. An estimate of this maximum power can be made from Pennycuick & Parker’s (1966) observation that pigeons can climb vertically at 250 cm./sec. when forced to take off close to an obstacle. Five observations of steep or vertical take-off on the high-speed film yielded flapping frequencies ranging from 9·1 to 9·7/sec., averaging 9·4/sec., and the sweep angle was taken to be 284°, the maximum anatomically possible. The power required for vertical climb was then calculated in the same way as was done earlier for horizontal flight.

Profile power worked out to be 5·6 W., and parasite power was 0·05 W. Induced power (4·9 W.) was considerably less than in hovering (8·4 W.), because the vertical climbing velocity increases the mass flow of air through the wing disk, thus reducing the induced velocity needed to maintain the required rate of change of momentum. The climbing power (product of weight and vertical velocity) was 9·8 W., and the total power required 20·4 W., or nearly twice the maximum continuous power. In the case of the pigeon it is no surprise to find a large difference between maximum power and maximum continuous power, since the work of J. C. George and co-workers (reviewed by George & Berger, 1966) has shown that a large part of the pigeon’s flight muscle is specialized for intermittent anaerobic operation. The ratio of these two powers would, however, be expected to vary widely in different flying animals.

A maximum value for M, averaging 10·2 kg. wt. cm., was found by Pennycuick & Parker (1966) by measuring the ultimate strength of the pectoralis insertion. A minimum value can be obtained by assuming that during the downstroke the wing must support at least half the weight, or 200 g. wt. for a 400 g. wt. pigeon. The position of the centre of lift of the wing in gliding (which would be much the same as in fast flapping flight) was estimated by Pennycuick (1967) to be 14·3 cm. from the centre of rotation of the shoulder joint, giving a minimum possible moment of 2·9 kg. wt. cm. These upper and lower limits are marked in Fig. 15.

It might be thought that the work done in imparting angular kinetic energy to the wing at the beginning of each downstroke and each upstroke should have been considered in the power calculation. This energy is, however, recoverable, since the wing can be slowed by aerodynamic forces at the end of the stroke, and its kinetic energy can, in principle, be transferred to the air. The power needed to oscillate the wing is thus included in induced and profile power, and need not be considered separately— in contrast to the case of a walking mammal, for instance, in which the biggest component of power is that needed to oscillate the legs.

When the forces applied to the structure are considered, the moments needed to accelerate the wings must be taken into account. In order to obtain some idea of the magnitude of these moments, the moment of inertia of a pigeon’s wing was estimated as follows.

This idea is supported by the fact that the wings are always raised farther above the horizontal position on the upstroke than they are depressed below it on the downstroke—in maximal flapping the wings are clapped togtether above the back, but the humeri are only depressed some 45° below the mid-point on the downstroke. The point is illustrated in Fig. 16, which is derived from the experiment described on page 528, and shows the average angular excursion of the wing in horizontal flight at various speeds. There would seem little aerodynamical advantage in raising the wings farther than they are lowered, and probably the early part of the downstroke is used mainly or solely for accelerating the wing.

The ratio of the ultimate moment, sufficient to break the pectoralis insertion, to the maximum moment likely to be developed in flight may be defined as the ‘structural safety factor’ of the pectoralis insertion. It is estimated as 1·6 at the maximum range speed, and 2·3 in vertical climbing. This may be compared with Machin & Pringle’s (1959) estimate that the tensile stress needed to tear the flight muscles of the beetle Oryctes rhinoceros is about 1·9 times the maximum stress developed in flight.

The general U-shape of the power-versus-speed curve of Fig. 12 probably applies to all flying animals, but the high-power portions at the two ends are caused by different factors, and are to some extent independent. The high power needed in hovering and at low speeds is due to the induced component, which can be reduced by reducing the disk loading. Thus animals specialized for hovering can economize on induced power (at the expense of high-speed performance) by evolving long wings, which may be the explanation of Greenewalt’s (1962) observation that the larger hummingbirds have disproportionately long wings as compared to the smaller ones.

The rise in the power curve at high speeds, on the other hand, is mainly due to the drag of the body, though wing-profile power (P_pro2) also contributes to it: it can be delayed to some extent by better streamlining of the body, and also by reduction of wing area.

In an attempt to make a comparison with an entirely different bird, a power curve was calculated for the ruby-throated hummingbird Archilochus colubris, by the same method as was used for the pigeon. The data required in the computer program were obtained from figures and drawings given by Greenewalt (1961, 1962), and are listed in the appendix. The results are plotted in Fig. 17. The maximum power line has been drawn to give the maximum level speed of 11·5 m./sec., recorded by Greenewalt (1961) for this species, and the maximum continuous power must lie between this and the hovering power (p. 550).

The best effective lift: drag ratio is estimated to be only 4·1 for this bird, but this corresponds to a range of 894 km./g. fat, achieved at 9 m./sec. (20 m.p.h.). If, as Lasiewski (1962) says, the bird can carry 2 g. of fat, it should be able to cross the Gulf of Mexico with a large safety margin, and the trip would take 25 hr. in no wind. The low speed at which maximum range is obtained, however, means that a headwind of only 4·5 m./sec. (10 m.p.h.) would double the time for the crossing and use up the fuel reserve, and from this point of view a long sea crossing is safer for a large bird which can cruise at a higher speed. As explained on page 541, the larger bird has no advantage in air range as such, by virtue of its size. The implications of the present study for the theory of bird migration are developed further by Pennycuick (1969).

The maximum estimated value of lift coefficient for the pigeon is 2·78 and occurs in hovering. The maximum value of 2·15 calculated for the ruby-throated humming bird occurs at 1·5 m./sec., and is somewhat higher than the hovering value ( 1·86). The general similarity of the range of estimated lift coefficients in the two species can be seen from Fig. 18.

Although the general U-shape of the power curve of Figs. 12 and 17 is likely to apply to all flying animals (as it does to helicopters), one would expect the relationships of the maximum, and maximum continuous, power levels to the curve to vary in a systematic way in animals of different size. The power required to fly and the power available from the muscles vary in different ways with the size of the animal, and the nature of the general trend can be deduced from a simple dimensional argument.

If the logarithms of P_a and P_r are plotted against the logarithm of the weight for flying animals of different size, the slope of the former line should be 2/3, and that of the latter 7/6 (Fig. 19). Even allowing for the rather vague nature of the above argument, the difference between these two slopes is so large that there is bound to be a sharp upper limit to the size of practicable flying animals. In practice the limit of mass for flying birds seems to be in the region of 12 kg. (with the crop empty), and is attained by some species of at laest three different orders—examples are the Kori bustard Ardeotis kori, the California condor Gymnogyps californianus and the trumpeter swan Cygnus cygnus.

Figure 20 illustrates the way in which the differing relationship of the maximum power available, P_am, and the maximum power continuously available, P_ac, to the power required, P_r, determines the general flight capabilities of four different-sized birds.

In the case of hummingbirds (Trochilidae), whose mass ranges from 2 to 20 g., it seems that sufficient power is available for hovering without incurring an oxygen debt—Lasiewski (1963) records a specimen of Calypte costae hovering continuously for 50 min. The P_ac line may therefore be drawn in above the hovering power (Fig. 20b), and the P_am line somewhat higher. The pigeon Columba livia (mass 400 g.) is an intermediate case in that the P line falls between the minimum power required (trough of curve) and the hovering power, whereas P_am is well above the hovering power. The pigeon is thus able to jump straight into the air on take-off and can climb vertically for perhaps a second if necessary, but it cannot fly continuously more slowly than about 3 m./sec. (Fig. 20a).

Turning now to very large birds, the larger African vultures (mass 5–7 kg.), such as the lappet-faced vulture Torgos tracheliotus and the white-backed vulture Pseudogyps africanas, cannot hover even briefly, but they can fly horizontally for short periods, possibly for 5 min. Thus both P_am and P_ac must lie between the minimum power required and the hovering power (Fig. 20c). It would appear from the account of Koford (1953) that the even larger California condor (mass up to 12 kg.) is probably not capable of continuous horizontal flight at all, and relies exclusively on soaring for protracted flight, flapping its wings only on take-off or in emergencies. If this is so, its P_am would lie above the trough of the power required curve, but P_ac would lie below it (Fig. 20 d).

It follows from diagrams of the type shown in Fig. 20c, d that large birds cannot jump into the air from flat ground like a pigeon, but must accelerate horizontally to a speed V_min, marked by the vertical dotted lines, at which they have sufficient power to maintain horizontal flight. If the bird takes off against a wind blowing at V_min or faster, it can, of course, become airborne at once, but in still air, on flat ground, V_min must be attained by running.

The heavier the bird, and the higher its wing-loading, the greater is V_min. Maximum running speed, however, does not increase noticeably with increasing size, and Hill (1950) showed that for geometrically similar animals running speed should be independent of size. Thus there must be a size of bird whose maximum running speed would be insufficient to accelerate it to V_min, and which could not, therefore, take off in no wind from flat ground, and it is possible that this factor places an upper limit on the size and/or wing-loading of large flying birds which inhabit flat country. An alternative method of taking off, which is normally available to mountain birds like the California condor, is to jump off some eminence, which avoids the need for a take-off run. It may be noted that birds are the only flying vertebrates which have ever been able to take off by running over the ground; in both bats and pterosaurs the legs are (or were) modified as part of the wing structure, and thereby rendered unsuitable for bipedal running. The larger members of these groups could therefore only take off by diving from a tree or hill.

The general level of performance measured or deduced for the pigeon is extremely poor by aeronautical engineering standards. Wing-profile drag coefficients ranging from 0·01 to 0·54 are deplorably high, as is the body-drag coefficient of 0·43, and the resulting estimate of about 6 for the best effective lift: drag ratio is far from impressive. However, these figures lead to entirely plausible estimates of the pigeon’s general flight capabilities, and there is no reason at present to doubt that its performance is indeed as poor as has been suggested. This is strongly supported by the very similar estimates of effective lift: drag ratio deduced from the measurements of Nisbet et al. (1963) and Tucker (1968), using different species and radically different methods (p. 542). The above calculation for the ruby-throated hummingbird confirms the same general impression.

The performance of model aircraft, operating in the same range of Reynolds numbers (20,000 – 300,000) as the birds mentioned here, is also very poor by comparison with that of full-scale aircraft. The latter mostly operate at Reynolds numbers of i million upwards, at which it is usually possible to keep the boundary layer laminar over a substantial fraction of the wing surface. Following the advice of Schmitz (1960), who investigated the behaviour of a number of aerofoil sections at low Reynolds numbers, aeromodellers commonly glue sandpaper or thread along the leading edge of their models’ wings, which ensures that the boundary layer is turbulent all over, since only in this case (at low Reynolds numbers) will the boundary layer remain attached to the wing surface over a useful range of angles of attack. The performance estimates for birds given here are consistent with the idea that they, too, maintain a fully turbulent boundary layer over the whole wing at all times, doubtless for the same reason.

In addition to those to whom my thanks are acknowledged in the preceding paper, I am most grateful to Dr L. C. Strong for carrying out the Soxhlet extraction mentioned on page 541.

The following data were used in the power calculations for the pigeon and ruby-throated hummingbird.
